GD32F3x0 User Manual

X001: PB7 pin

X010: PC7 pin

X011: Reserved

X100: Reserved

X101: PF7 pin

X110: Reserved

X111: Reserved

11:8

EXTI6_SS[3:0]

EXTI 6 sources selection

X000: PA6 pin

X001: PB6 pin

X010: PC6 pin

X011: Reserved

X100: Reserved

X101: PF6 pin

X110: Reserved

X111: Reserved

7:4

EXTI5_SS[3:0]

EXTI 5 sources selection

X000: PA5 pin

X001: PB5 pin

X010: PC5 pin

X011: Reserved

X100: Reserved

X101: PF5 pin

X110: Reserved

X111: Reserved

3:0

EXTI4_SS[3:0]

EXTI 4 sources selection

X000: PA4 pin

X001: PB4 pin

X010: PC4 pin

X011: Reserved

X100: Reserved

X101: PF4 pin

X110: Reserved

X111: Reserved

1.6.4. EXTI sources selection register 2 (SYSCFG_EXTISS2)

Address offset: 0x10

Reset value: 0x0000 0000

This register has to be accessed by word(32-bit).
