GD32F3x0 User Manual

155

9.4.9. DMA request mapping

Several requests from peripherals may be mapped to one DMA channel. They are logically

ORed before entering the DMA. For details, see the following Figure 9-4. DMA request

mapping. The request of each peripheral can be independently enabled or disabled by

programming the registers of the corresponding peripheral. The user has to ensure that only

one request is enabled at a time on one channel. Table 9-3. DMA requests for each

channel lists the support request from peripheral for each channel of DMA.
