GigaDevice Semiconductor GD32F3x0 - EXTI Sources Selection Register 1 (SYSCFG

To Next Page

To Previous Page

GD32F3x0 User Manual

X010: PC2 pin

X011: PD2 pin

X100: Reserved

X101: Reserved

X110: Reserved

X111: Reserved

7:4

EXTI1_SS[3:0]

EXTI 1 sources selection

X000: PA1 pin

X001: PB1 pin

X010: PC1 pin

X011: Reserved

X100: Reserved

X101: PF1 pin

X110: Reserved

X111: Reserved

3:0

EXTI0_SS[3:0]

EXTI 0 sources selection

X000: PA0 pin

X001: PB0 pin

X010: PC0 pin

X011: Reserved

X100: Reserved

X101: PF0 pin

X110: Reserved

X111: Reserved

1.6.3. EXTI sources selection register 1 (SYSCFG_EXTISS1)

Address offset: 0x0C

Reset value: 0x0000 0000

This register has to be accessed by word (32-bit).

Reserved

EXTI7_SS [3:0]

EXTI6_SS [3:0]

EXTI5_SS [3:0]

EXTI4_SS [3:0]

Bits

Fields

Descriptions

31:16

Reserved

Must be kept at reset value

15:12

EXTI7_SS[3:0]

EXTI 7 sources selection

X000: PA7 pin
