Detect Model: Semi-auto Detect.
Source Channel: The source channel to be detected.
Destination Number: The number to be dialed for detecting. This number could be a cell phone number
or other PSTN number that can be reached from the source channel PSTN number.
5. Click "Detect" to start detecting. The source channel will initiate a call to the destination number. For "Auto
Detect", the call will be automatically answered. For "Semi-auto Detect", the UCM6200 Web GUI will display
prompt to notify the user to answer or hang up the call to finish the detecting process.
6. Once done, the detected result will show. Users could save the detecting result as the current UCM6200
settings.
Table 50: PSTN Detection for Analog Trunk
Detect Model
Select "Auto Detect" or "Semi-auto Detect" for PSTN detection.
• Auto Detect
Please make sure two or more channels are connected to the
UCM6200 and in idle status before starting the detection. During the
detection, one channel will be used as caller (Source Channel) and
another channel will be used as callee (Destination Channel). The
UCM6200 will control the call to be established and hang up between
caller and callee to finish the detection.
• Semi-auto Detect
Semi-auto detection requires answering or hanging up the call
manually. Please make sure one channel is connected to the
UCM6200 and in idle status before starting the detection. During the
detection, source channel will be used as caller and send the call to
the configured Destination Number. Users will then need follow the
prompts in Web GUI to help finish the detection.
The default setting is "Auto Detect".
Source Channel
Select the channel to be detected.
Destination Channel
Select the channel to help detect when "Auto Detect" is used.
Destination Number
Configure the number to be called to help the detection.
----------------------------------------------------------------------------------------------------------------------------- ----------------------
Note:
• The PSTN detection process will keep the call up for about 1 minute.
• If "Semi-auto Detect' is used, please pick up the call only after informed from the Web GUI prompt.
• Once the detection is successful, the detected parameters "Busy Tone", "Polarity Reversal" and "Current
Disconnect by PSTN" will be filled into the corresponding fields in the analog trunk configuration.
----------------------------------------------------------------------------------------------------------------------------- ----------------------
