User could also filter the operation logs by time condition, IP address and/or username. Configure these

conditions and then click on .

Figure 328: Operation Logs Filter

In the figure above, an example that shows operations made by user “support” on device with IP 192.168.40.173

from 2014-11-01 00:00 to 2014-11-06 15:38 are filtered out and displayed.

Users can either filter out specific operation logs or then click on the button to delete

the filtered results or click on the button to delete all operation logs. Note: Deleting operation

logs will generate an operation log entry detailing the action.

Upgrading

The UCM6200 can be upgraded to a new firmware version remotely or locally. This section describes how to

upgrade your UCM6200 via network or local upload.
