UCM6200 Series User Manual
Version 1.0.20.38
Enter the Prefix length for static settings. Default is 64
Enter the DNS server 1 address for static settings.
Enter the DNS server 2 address for static settings.
LAN 1 / LAN 2 (when Method is set to "Dual")
Users must select either LAN 1 (WAN port) or LAN 2 (LAN port) to be used as the default
interface. Default setting is LAN 2.
Select Auto or Static. The default setting is Auto
Enter the IP address for static IP settings.
Enter the Prefix length for static settings. Default is 64
Enter the DNS server 1 address for static settings.
Enter the DNS server 2 address for static settings.
• Method: Route
When the UCM6200 has, method set to Route in network settings, WAN port interface is used for uplink
connection and LAN port interface is used as a router. Please see the sample diagram below.
Figure 11: UCM6202 Network Interface Method: Route
• Method: Switch
WAN port interface is used for uplink connection; LAN port interface is used as room for PC connection.
