UCM6200 Series User Manual
Version 1.0.20.38
route when no others are available or can serve as complementary routes alongside existing routes as failover
routes, with existing routing on the UCM6200 as a failover backup, etc.
• Click on to create a new IPv4 static route or click on to
create a new IPv6 static route. The configuration parameters are listed in the table below.
• Once added, users can select to edit the static route.
• Select to delete the static route.
Table 9: UCM6200 Network Settings→Static Routes
Configure the destination IPv4 address or the destination IPv6 subnet for the
UCM6200 to reach using the static route.
Example:
IPv4 address - 192.168.66.4
IPv6 subnet - 2001:740:D::1/64
Configure the subnet mask for the above destination address. If left blank, the
default value is 255.255.255.255.
Example:
255.255.255.0
Configure the IPv4 or IPv6 gateway address so that the UCM6200 can reach the
destination via this gateway. Gateway address is optional.
Example:
192.168.40.5 or 2001:740:D::1
Specify the network interface on the UCM6200 to reach the destination using the
static route.
LAN interface is eth0; WAN interface is eth1.
Static routes configuration can be reset from LCD menu→Network Menu.
The following diagram shows a sample application of static route usage on UCM6204.
