Figure 272: UCM & HSC PMS interaction

Mitel PMS

In this mode, the system can be divided into two parts:

• PMS (Property Management System)

• PBX

Grandstream UCM6XXX series have integrated Mitel PMS providing following hospitality features: Check-in,

Check-out, set Room Status, Wake-up call and more.

The following figure illustrates the communication flow between the PBX (Grandstream UCM6xxx Series) and

PMS software (Mitel). The communication between both parties is direct with no middleware.

Figure 273: UCM & Mitel PMS interaction

HSC PMS Software

Grandstream UCM

Mitel PMS Software

Grandstream UCM
