P a g e | 46

UCM6200 Series User Manual

Version 1.0.20.38

INSTALLATION

Before deploying and configuring the UCM6200 series, the device needs to be properly powered up and

connected to a network. This section describes detailed information on installation, connection and warranty

policy of the UCM6200 series.

Equipment Packaging

Table 2: UCM6200 Equipment Packaging

Main Case

Power Adaptor

Ethernet Cable

Quick Installation Guide

GPL License

Connect Your UCM6200

Connect the UCM6202

Figure 1: UCM6202 Front View
