UCM6200 Series User Manual
Version 1.0.20.38
Uploads the private key for the HTTP server.
Note: Key file must be under 2MB in file size and in *.pem format. File
name will automatically be changed to "private.pem".
Uploads the certificate for the HTTP server.
Note: Certificate must be under 2MB in file size and in *.pem format. This
will be used for TLS connections and contains private key for the client
and signed certificate for the server.
Enter the domain to request the certificate for and click on
to request the certificate.
If the protocol or port has been changed, the user will be logged out and redirected to the new URL.
Network Settings
After successfully connecting the UCM6200 to the network for the first time, users could login the Web GUI and
go to System Settings→Network Settings to configure the network parameters for the device.
• UCM6200 supports Route/Switch/Dual mode functions.
In this section, all the available network setting options are listed for all models. Select each tab in Web
GUI→System Settings→Network Settings page to configure LAN settings, WAN settings, 802.1X and Port
Forwarding.
Basic Settings
Please refer to the following tables for basic network configuration parameters on UCM6202, UCM6204 and
UCM6208, respectively.
Table 7: UCM6200 Network Settings→Basic Settings
Select "Route", "Switch" or "Dual" mode on the network interface of UCM6200. The default
setting is "Route".
• Route
WAN port will be used for uplink connection. LAN port will function similarly to a regular
router port.
• Switch
WAN port will be used for uplink connection. LAN port will be used as a bridge for
connections.
