UCM6200 Series User Manual
Version 1.0.20.38
the default ring timeout is 60 seconds on the UCM6200, which can be configured in
the global ring timeout setting under Web GUI→PBX Settings→Voice
Prompt→Custom Prompt: General Preference. The valid range is between 5 seconds
and 600 seconds.
Note: If the end point also has a ring timeout configured, the actual ring timeout used
is the shortest time set by either device.
Auto Record
Enable automatic recording for the calls using this extension. The default setting is
disabled. The recording files can be accessed under Web GUI→CDR→Recording
Files.
Skip Trunk Auth
• If set to “Yes”, users can skip entering the password when making outbound calls.
• If set to “By Time”, users can skip entering the password when making outbound
calls during the selected time condition.
• If set to “No”, users will be asked to enter the password when making outbound
calls.
Time Condition for
Skip Trunk Auth
If “Skip Trunk Auth” is set to “By Time”, select a time condition during which users can
skip entering password when making outbound calls.
Dial Trunk
Password
Configure personal password when making outbound calls via trunk.
Enable LDAP
If enabled, the extension will be added to LDAP Phonebook PBX lists.
Music On Hold
Configure the Music On Hold class to suggest to the bridged channel when putting
them on hold.
Call Duration Limit
The maximum duration of call-blocking.
Table 39: IAX Extension Configuration Parameters→Specific Time
Specific Time
Time Condition
Click to add Time Condition to configure specific time for this extension.
Create New FXS Extension
The UCM6200 supports Foreign eXchange Subscriber (FXS) interface. FXS is used when user needs to connect
analog phone lines or FAX machines to the UCM6200.
To manually create new FXS user, go to Web GUI→Extension/Trunk→Extensions. Click on "Add" and a new
dialog window will show for users which need to make sure first to select the extension type to be FXS Extension
before proceeding to fill in the extension information. The configuration parameters are as follows.
Table 40: FXS Extension Configuration Parameters→Basic Settings
General
Extension
The extension number associated with the user.
