selected module.

Contact Lookups

Select from the “Available” list of lookups and press to

select where the UCM can perform the lookups on the CRM tables,

Leads, Accounts, and Contacts.

Once settings on admin access are configured:

2. Click on and .

3. Logout from admin access.

4. Login to the UCM as user and navigate under “User Portal→Value-added Feature→CRM User Settings”.

Click on “Enable CRM” and enter the username/password associated with the CRM account then click on

and . The status will change from “Logged Out” to “Logged In”. User can start then using

SugarCRM features.

Figure 262: CRM User Settings

vTigerCRM

Configuration page of the vTigerCRM can be accessed via admin login, on the UCM webGUI→Value-added

Features→CRM.
