Grandstream Networks UCM6200 Series User Manual

P a g e | 378
UCM6200 Series User Manual
Version 1.0.20.38
Permitted IP(s)
Specify a list of IP addresses permitted to use the API. This creates an API-specific
access control list. Multiple entries are allowed.
For example, "192.168.40.3/255.255.255.255" denies access from all IP addresses
except 192.168.40.3.
By default, this is blank, which indicates that no IP addresses are allowed to use
this API.
Other Settings
TLS Private Key
Upload TLS private key. The size of the key file must be under 2MB. This file will be
renamed as 'private.pem' automatically.
TLS Cert
Upload TLS cert. The size of the certificate must be under 2MB. This is the certificate
file (*.pem format only) for TLS connection. This file will be renamed as
"certificate.pem" automatically. It contains private key for the client and signed
certificate for the server.
API Module
CDR API
Enable/disable CDR API module.
REC API
Enable/disable REC API module.
PMS API
Enable/disable PMS API module.
For more details on CDR API (Access to Call Detail Records), REC API (Access to Call Recording Files) and
PMS API, please refer the document in the link here:
• CDR API
• REC API
• PMS API
CDR Real-time Output Settings
CDR Real-time output feature allows to automatically send CDR records once available (after the call is
terminated) to a specified server address.
Table 117: CDR Real-time Output Settings
CDR Real-time Output Settings
Enable
Enables real-time CDR output module. This module connects to selected IP
addresses and ports and posts CDR strings as soon as it is available.
Server Address
CDR server IP address
Port
CDR server IP port
