P a g e | 428

UCM6200 Series User Manual

Version 1.0.20.38

Figure 313: CDR Statistics

Table 141: CDR Statistics Filter Criteria

Trunk Type

Select one of the following trunk types.

• All

• SIP Calls

• PSTN Calls

Call Type

Select one or more in the following checkboxes.

• Inbound calls

• Outbound calls

• Internal calls

• External calls

• All calls

Time Range

• By month (of the selected year).

• By week (of the selected year).

• By day (of the specified month for the year).

• By hour (of the specified date).

• By range. For example, 2016-01 To 2016-03.
