UCM6200 Series User Manual
Version 1.0.20.38
Figure 18: UCM6200 Using 802.1X EAP-MD5
The following table shows the configuration parameters for 802.1X on UCM6200. Identity and MD5 password
are required for authentication, which should be provided by the network administrator obtained from the
RADIUS server. If “EAP-TLS” or “EAP-PEAPv0/MSCHAPv2” is used as the 802.1X mode, users will also need
to upload 802.1X CA Certificate and 802.1X Client Certificate, which should be also generated from the RADIUS
server.
Table 8: UCM6200 Network Settings→802.1X
Select 802.1X mode. The default setting is "Disable". The supported 802.1X
modes are:
• EAP-MD5
• EAP-TLS
• EAP-PEAPv0/MSCHAPv2
Enter 802.1X mode Identity information.
Enter 802.1X mode MD5 password information.
Select 802.1X certificate from local PC and then upload.
802.1X Client
Certificate
Select 802.1X client certificate from local PC and then upload.
Static Routes
The UCM6200 provides users static routing capability that allows the device to use manually configured
routes, instead of dynamically assigned routes or the default gateway. Static routes can be used to define a
