Table 76: 2-way Intercom Configuration Parameters

Name

Configure paging/intercom group name.

Type

Select "2-way Intercom".

Extension

Configure the paging/intercom group extension.

Replace Display Name

If enabled, the UCM will replace the caller display name with Paging/Intercom

name.

Maximum Call Duration

Specify the maximum call duration in seconds. The default value 0 means no

limit.

Custom Prompt

This option is to set a custom prompt for a paging/intercom group to announce

to caller. Users can now directly upload custom prompts from this page. They

do not need to be redirected anymore.

Members

Select available users from the left side to the paging/intercom group member

list on the right.

Paging/Intercom

Whitelist

Select which extensions are allowed to use the paging/intercom feature for this

paging group.

Configure 1-way Paging

Figure 177: 1-way Paging
