Cleaner Options

Enable Conference

Schedules Cleaner

If this option is enabled, conference schedules will be automatically cleaned as

configured.

Conference

Schedules Clean

Time

Enter the clean time (in hours). The valid range is from 0 to 23.

Clean Interval

Enter the clean interval (in days). The valid range is from 1 to 30.

After configuring the scheduled conference, it will be shown under Conference Schedule page as below:

Figure 139: Conference Schedule
