Table 74: Restrict Calls Configuration Parameters

Name

Configure Restrict call’s name.

Restrict Calls between

extensions

When enabled, members of the group cannot dial other extension, only the

numbers in the Allowed List.

Members

Configure the members that will not be able to call any extensions besides those

in the Allowed List.

Allowed list

Select the extensions that the Members list can be able to call.
