UCM6200 Series User Manual
Version 1.0.20.38
SYSTEM SETTINGS
This section will explain the available system-wide parameters and configuration options on the UCM62xx. This
includes settings for the following items: HTTP server, network, OpenVPN, DDNS, LDAP server and email
server.
HTTP Server
The UCM6200's embedded web server responds to HTTP/HTTPS GET/POST requests and allows users to
configure the UCM via web browsers such as Microsoft IE, Mozilla Firefox, and Google Chrome. By default,
users can access the UCM by just typing its IP address into a browser address bar. The browser will automatically
be redirected to HTTPS using port 8089. For example, typing in "192.168.40.50" into the address bar will redirect
the browser to "https://192.168.40.50:8089". This behavior can be changed in the System Settings->HTTP
Server page.
Table 6: HTTP Server Settings
Toggles automatic redirection to UCM's web portal from port 80. If
disabled, users will need to manually add the UCM's configured
HTTP/HTTPS port to the server address when accessing the UCM web
portal via browser. Default is "Enabled".
Select either HTTP or HTTPS as the protocol to access the UCM's HTTP
server. This will also determine what is used when endpoints download
config files from the UCM via Zero Config. Default is "HTTPS".
Specifies the port number used to access the UCM HTTP server. Default
is "8089".
If enabled, only the server addresses in whitelist will be able to access the
UCM's web portal. It is highly recommended to add the IP address
currently used to access the UCM web page before enabling this option.
Default is "Disabled".
List of addresses that can access the UCM web portal.
Ex: 192.168.6.233 / 255.255.255.255
Selects the method of acquiring SSL certificates for the UCM web server.
Two methods are currently available:
- Upload Certificate: Upload the appropriate files from one's own PC.
- Request Certificate: Enter the domain for which to request a certificate
for from Let's Encrypt.
