UCM6200 Series User Manual
Version 1.0.20.38
PRODUCT OVERVIEW
Technical Specifications
The following table resumes all the technical specifications including the protocols / standards supported, voice
codecs, telephony features, languages and upgrade/provisioning settings for UCM6200 series.
Table 1: Technical Specifications
Interfaces
Analog Telephone FXS
Ports
2x RJ11 ports with lifeline support
Each port supports 2 REN
PSTN Line FXO Ports
• UCM6202: 2 ports
• UCM6204: 4 ports
• UCM6208: 8 ports
Network Interfaces
UCM6202/6204/6208:
1x Gigabit WAN port
1x Gigabit LAN port with PoE Plus (IEEE 802.3at-2009)
NAT Router
Yes
Peripheral Ports
USB 2.0, SD
LED Indicators
Power/Ready, Network, PSTN Line, USB, SD
LCD Display
128x32 graphic LCD with DOWN and OK button
Reset Switch
Yes
Voice/Video Capabilities
Voice-over-Packet
Capabilities
128ms tail-length carrier-grade Line Echo Cancellation with NLP Packetized Voice
Protocol Unit, dynamic jitter buffer, modem detection, and auto-switch to G.711.
Voice and Fax Codecs
G.711 A-law/U-law, G.722, G.723.1 5.3K/6.3K, G.726, G.729A/B, iLBC (30ms
only), GSM, AAL2-G.726-32, RTX, ADPCM; T.38
Video Codecs
H.264, H.265, H.263, H.263+, VP8
QoS
Layer 3 QoS, Layer 2 QoS
Signaling and Control
DTMF Methods
Inband, RFC4733, and SIP INFO
Provisioning Protocol and
Plug-and-Play
TFTP/HTTP/HTTPS, auto-discovery and auto-provisioning of Grandstream IP
endpoints via ZeroConfig (DHCP Option 66/multicast SIP SUBSCRIBE/mDNS),
Eventlist between local and remote trunk
Network Protocols
TCP/UDP/IP, RTP/RTCP, ICMP, ARP, DNS, DDNS, DHCP, NTP, TFTP, SSH,
HTTP/HTTPS, PPPoE, SIP (RFC3261), STUN, SRTP, TLS, LDAP/LDAPS
Disconnect Methods
Call Progress Tone, Polarity Reversal, Hook Flash Timing, Loop Current
