UCM6200 Series User Manual
Version 1.0.20.38
Time Condition
Start Time
Select the start time "hour:minute" for the trunk to use the inbound rule.
End Time
Select the end time "hour:minute" for the trunk to use the inbound rule.
Frequency
Select either "By Week" or "By Month" for the time condition.
If "By Week" is selected, select the weekdays that the time condition will be
used.
If "By Month" is selected, select the months that the time condition will be
used. Next, select either "Week" or "Day".
(1) If "Week" is selected, choose the weekdays of the month that the time
condition will be used.
(2) If "Day" is selected, choose the specific days of the month that the time
condition will be used.
Destination
Select the destination for the inbound call under the defined time condition.
• Extension
• Voicemail
• Conference Room
• Call Queue
• Ring Group
• Paging/Intercom
• Voicemail Group
• Fax
• DISA
• IVR
• By DID
When "By DID" is used, the UCM will look for the destination based on
the number dialed, which could be local extensions, conference, call
queue, ring group, paging/intercom group, IVR, voicemail groups and Fax
extension as configured in "DID destination". If the dialed number
matches the DID pattern, the call will be allowed to go through.
Configure the number of digits to be stripped in "Strip" option.
• Dial By Name
• External Number
• Callback
• Announcement
Inbound Route: Prepend Example
UCM6200 now allows user to prepend digits to an inbound DID pattern, with strip taking precedence over
prepend. With the ability to prepend digits in inbound route DID pattern, user no longer needs to create multiple
routes for the same trunk to route calls to different extensions. The following example demonstrates the process:
