P a g e | 281

UCM6200 Series User Manual

Version 1.0.20.38

Table 80: Schedule Paging / Intercom Settings

Figure 182: Creating a scheduled paging/intercom call

Caller

Configure the caller ID for the paging / intercom group.

Paging/Intercom Group

Select the paging / intercom group from the list of the available groups.

Start Time

Configure the start time of the scheduled paging / intercom call.

Type

Select the type for the scheduled paging / intercom call. The available types are:

Single time or Daily, Weekly basis. Default is “Single”.

Include Holidays

If enabled Paging/Intercom will run during holidays.

Action Status

Display the action status of the scheduled paging / intercom call.
