IVR

Configure IVR

IVR configurations can be accessed under the UCM6200 Web GUI→Call Features→IVR. Users could create,

edit, view and delete an IVR.

• Click on "Create New IVR" to add a new IVR.

• Click on to edit the IVR configuration.

• Click on to delete the IVR.

Figure 155: Create New IVR
