P a g e | 324

UCM6200 Series User Manual

Version 1.0.20.38

Figure 220: Create New Event List

Table 93: Event List Settings

URI

Configure the name of this event list (for example, office_event_list). Please note

the URI name cannot be the same as the extension name on the UCM6200. The

valid characters are letters, digits, _ and -.

Local Extensions

Select the available extensions/Extension Groups listed on the local UCM6200

to be monitored in the event list.

Remote Extensions

If LDAP sync is enabled between the UCM6200 and the peer UCM6200, the

remote extensions will be listed under "Available Extensions". If not, manually

enter the remote extensions under "Special Extensions" field.
