Grandstream Networks UCM6200 Series User Manual

P a g e | 62
UCM6200 Series User Manual
Version 1.0.20.38
Password
Enter the password to connect via PPPoE.
Layer 2 QoS
802.1Q/VLAN
Tag
Assign the VLAN tag of the layer 2 QoS packets for LAN port. The default value is 0.
Layer 2 QoS
802.1p Priority
Value
Assign the priority value of the layer 2 QoS packets for LAN port. The default value is 0.
IPv6 Address
WAN (when "Method" is set to "Route")
IP Method
Select Auto or Static. The default setting is Auto
IP Address
Enter the IP address for static IP settings.
IP Prefixlen
Enter the Prefix length for static settings. Default is 64
DNS Server 1
Enter the DNS server 1 address for static settings.
DNS Server 2
Enter the DNS server 2 address for static settings.
LAN (when Method is set to "Route")
DHCP Server
Select Disable, Auto or DHCPv6.
Disable: Disables the DHCPv6 server.
Auto: Stateless address auto configuration using NDP protocol.
DHCPv6: Stateful address auto configuration using DHCPv6 protocol.
DHCP Prefix
Enter DHCP prefix. (Default is 2001:db8:2:2::)
DHCP
prefixlen
Enter the Prefix length for static settings. Default is 64
DNS Server 1
Enter the DNS server 1 address for static settings. Default is (2001:4860:4860::8888 )
DNS Server 2
Enter the DNS server 2 address for static settings. Default is (2001:4860:4860::8844 )
Allow IP
Address From
Configure starting IP address assigned by the DHCP prefix and DHCP prefixlen.
Allow IP
Address To
Configure the ending IP address assigned by the DHCP Prefix and DHCP prefixlen.
Default IP
Lease Time
Configure the lease time (in second) of the IP address.
LAN (when Method is set to "Switch")
IP Method
Select Auto or Static. The default setting is Auto
IP Address
Enter the IP address for static IP settings.
