UCM6200 Series User Manual
Version 1.0.20.38
Enter the DHCP IP Pool ending address. The default setting is 192.168.2.254.
Enter the IP lease time (in seconds). The default setting is 43200.
LAN (when Method is set to "Switch")
Select DHCP, Static IP, or PPPoE. The default setting is DHCP.
Enter the IP address for static IP settings. The default setting is 192.168.0.160.
Enter the subnet mask address for static IP settings. The default setting is 255.255.0.0.
Enter the gateway IP address for static IP settings. The default setting is 0.0.0.0.
Enter the DNS server 1 address for static IP settings. The default setting is 0.0.0.0.
Enter the DNS server 2 address for static IP settings.
Enter the username to connect via PPPoE.
Enter the password to connect via PPPoE.
Layer 2 QoS
802.1Q/VLAN
Tag
Assign the VLAN tag of the layer 2 QoS packets for LAN port. The default value is 0.
Layer 2 QoS
802.1p Priority
Value
Assign the priority value of the layer 2 QoS packets for LAN port. The default value is 0.
LAN 1 / LAN 2 (when Method is set to "Dual")
If "Dual" is selected as the Method, users must select either LAN 1 (WAN port) or LAN 2
(LAN port) to be used as the default interface. Default setting is LAN 2.
Select DHCP, Static IP, or PPPoE. The default setting is DHCP.
Enter the IP address for static IP settings.
The default setting is 192.168.0.160.
Enter the subnet mask address for static IP settings. The default setting is 255.255.0.0.
Enter the gateway IP address for static IP settings when the port is assigned as default
interface. The default setting is 0.0.0.0.
Enter the DNS server 1 address for static IP settings.
The default setting is 0.0.0.0.
Enter the DNS server 2 address for static IP settings.
Enter the username to connect via PPPoE.
