P a g e | 293

UCM6200 Series User Manual

Version 1.0.20.38

Virtual Queue Callback Key Settings

Call Back Current

Number

Press the feature key configured to set your current number as callback number.

Custom Callback

Number

Press the feature key configured to set a custom callback number.

Continue Waiting

Press the feature key configured to continue waiting.
