P a g e | 89

UCM6200 Series User Manual

Version 1.0.20.38

• LDAP Name Filter: (CallerIDName=%)

• LDAP Display Name: AccountNumber CallerIDName

• LDAP Version: If existed, please select LDAP Version 3

• Port: 389

The following figure shows the configuration information on a Grandstream GXP2170 to successfully use the

LDAP server as configured in [Figure 33: LDAP Server Configurations].
