Theory of Operation 2-59
Drive Gears
The gears involved in feeding print media into the printer are identified in the
following figure.
s6300-070
Feeder Drive
Assembly
Turn Clutch
Assembly
Idle Gear 21/29
Gear 24
Feed Gear 2
Feed Gear 2
Gear Idler Feed
Feed Gear H1Feed Gear H2
Front
