2-54 Phaser 6300/6350 Color Laser Printer Service Manual
Drive Gears
The gears involved in feeding print media into the printer are identified in the
following figure.
s6300-076
Feeder Drive Assy
Turn Clutch Assy
Idle Gear 21/29
Idle Gear 21/29
Gear 24
Gear 24
Feed Gear 2
Feed Gear 2
Gear Idler Feed
Feed Gear 2
Gear Idler Feed
Feed Gear H1
Feed Gear H2
Front
Turn Clutch Assy
Feed Gear 2Feed Gear H1Feed Gear H2
