10-18 Phaser 6300/6350 Color Laser Printer Service Manual
Tray 2
P/J472
3
ENGINE CONTROL
BOARD
PL9.1.16
P/J47
1
2
4
3
+3.3VDC
PAPER SIZE
SWITCH
PL3.2.5
CST1 SIZE0 SWITCH ON(L)+3.3VDC
CST1 SIZE1 SWITCH ON(L)+3.3VDC
SG
CST1 SIZE2 SWITCH ON(L)+3.3VDC
P/J471
4
3
1
2
NO PAPER SENSOR
PL3.3.7
2
1
P/J47
5
6
7
PULL UP +3.3VDC
SG
CST1 NO PAPER SENSED(H)+3.3VDC
P/J473
3
LOW PAPER SENSOR
PL3.3.7
2
1
P/J47
8
9
10
PULL UP +3.3VDC
SG
CST1 LOW PAPER SENSED(H)+3.3VDC
P/J47
11
12
TRAY 1 (MPT)
FEED SOLENOID
PL3.3.11
P474
2
J474
1
1 2
I/L +24VDC
CST1 FEED SOL ON(L)+24VDC
+3.3VDC
Interlock
+24VDC
s6300-321
To Next Page
