9-62 Phaser 6300/6350 Color Laser Printer Service Manual
Sensor Acutator Kit
The Sensor Actuator Kit provides replacement actuators for the key paper path
sensors. Repalcement springs for most of these actuators are included in the Kit.
Long-Life Maintenance Kit
Install the Long-Life Maintenance Kit when the printer displays the Replace
Maintenance Kit error message.
Sensor Actuator Kit Contents - 116-2032-00
Part Reference Name/Description Quantity
PL3.3.14 Low Paper Sensor Actuator 2
PL3.3.20 No Paper Sensor Actuator 2
PL4.1.1 Registration Sensor Actuator 1
PL5.1.2 Fuser Exit Sensor Actuator 1
PL5.3.15 Tray 1 (MPT) No Paper Sensor Actuator 1
PL5.4.2 Full Stack Sensor Actuator 1
PL5.4.13 Duplex Jam Sensor Actuator 1
Long-Life Maintenance Kit Contents - 650-4363-00
Part Reference Part Number Name/Description Quantity
PL2.1.12 116-2035-00 Universal Tray Retard Roller Assembly 1
PL4.1.13 116-1985-00 Tray 1 (MPT) Retard Roller Assembly 1
PL4.2.1 116-1987-00 Registration Roller Assembly 1
PL5.3.20 116-1997-00 Tray 1 (MPT) Feed Roller 1
PL7.1.17 116-2008-00 Developer Assembly - Y 1
PL7.1.18 116-2009-00 Developer Assembly - M 1
PL7.1.19 116-2010-00 Developer Assembly - C 1
PL7.1.20 116-2011-00 Developer Assembly - K 1
