Xerox Phaser 6300 Service Manual

General Information 1-15
Image Specifications
Imaging Unit Cleaning Cycle Intervals
Cleaning cycle intervals decrease as the Imaging Unit print volume (life count)
increases. Other factors, such as print mode and area of coverage per print can also
increase the frequency of cleaning cycles irrespective of the Imaging Unit life count.
a. 36 ppm (6350 standard mode)
b. 26 ppm (6300 standard & Enhanced mode)
c. 18 ppm (Most specialty medias and Photo mode)
d. 12 ppm (Thick Card & envelopes)
Characteristic Specification
Maximum Print Area
a
Guaranteed Print Area
b
a. Set margin area within 2.5 mm from each of side edge and 2.0 mm from each of
top/bottom edge.
b. The printer prints images meeting the Print Quality Specification except the margin
area, which is 4.0 mm inside each edge of the paper.
210.9 mm (8.3 inches) x 890 mm (35 inches)
207.9 mm (8.2 inches) x 347.6 mm (13.7 inches)
Skew
± 1.2 mm across 190 mm image
Registration
Leading Edge
Side Edge
Duplex (front to back)
± 2.0 mm
± 2.5 mm
± 4.0 mm
Parallelism ± 1.2 mm across 234 mm image
Linearity
Vertical
Horizontal
Slant
± 0.5 mm across 234 mm image
± 0.5 mm across 190 mm image
± 1.2 mm across 269 mm image
Imaging Unit
Print Volume
Cleaning Cycle Interval
B/W Speed Color Speed
36 ppm 18 ppm 12 ppm 36 ppm 26 ppm 18 ppm 12 ppm
0 - 5120 108 54 39 72 52 36 26
5121 - 10240 72 36 26 48 35 34 17
10241 - 15360 72 36 26 48 35 34 17
15361 - 20480 72 36 26 48 35 34 17
20481 - 25600 54 27 20 36 26 18 13
25601 - 30720 54 27 20 36 26 18 13
above 30721 54 27 20 36 26 18 13
