10-34 Phaser 6300/6350 Color Laser Printer Service Manual
Drive
OPTFDR 1 BOARD
PL11.1.10
P/J82
1
2
3
4
5
I/L +24VDC
FDR_A
FDR_B
FDR_XA
FDR_XB
DRIVE ASSY
PL11.3.15
ENGINE CONTROL
BOARD
PL9.1.16
P/J17
10
9
8
7
6
5
4
3
2
1
P/J83
1
2
3
4
5
6
7
8
9
10
I/L+24VDC
SG
I/L+24VDC
SG
SG
+3.3VDC
SG
TRY_SNS
TXD
RXD
P171
1
J171
10
2 9
3 8
4 7
5 6
6 5
7 4
8 3
9 2
101
+3.3VDC
Interlock
+24VDC
Interlock
+24VDC
+3.3VDC
s6300-33
3
