Error Messages and Codes 3-13
Jam at Duplex: Jam D
The Duplex Jam Sensor indicates that paper did not reach the sensor on time or that
paper remains in the Chute Assembly Out.
Applicable Status Code:
Code 153: Jam at Duplex
Initial Actions:
■ Check for obstructions or debris in the Chute Assembly Out or paper path.
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack References
■ Duplex Jam Sensor, PL5.4.1
■ Jam Sensor Actuator, PL5.4.13
■ Duplex Motor Assembly, PL5.4.5
■ FRONT/DUP Harness, PL5.3.28
■ Chute Assembly Out, PL5.3.1
■ Print Engine Map 1 P/J Locator (page 10-5)
■ Print Engine Drive Wiring Diagram (page 10-19)
■ Print Engine Paper Feed Wiring (page 10-26)
Troubleshooting Procedures Table
Step Action and Questions Yes No
1
Check the following for evidence of fault or
damage:
■ Duplex Motor Assembly, PL5.4.5
■ JAM Sensor Actuator, PL5.4.13
■ Chute Assembly Out, PL5.3.1
Are there any defects?
Replace any
damaged part.
Go to Step 2.
2
Test the Duplex Jam Sensor.
Run the Service Diagnostics Jam Sensor
test.
Does the sensor function correctly?
Go to Step 7. Replace the
Duplex Jam
Sensor and
Go to Step 3.
3
Check printer function.
Does the printer function correctly after
replacing the Duplex Jam Sensor?
Complete Go to Step 4.
4
Check the Duplex Jam Sensor signal.
Block the Duplex Jam Sensor.
Is the voltage across J133-1 <=> J133-2
0 V?
Go to Step 6. Go to Step 5.
To Next Page
