Xerox Phaser 6300 Service Manual

10-26 Phaser 6300/6350 Color Laser Printer Service Manual
Paper Feed
ENGINE CONTROL
BOARD
PL9.1.16
P/J13
7
8
9
P/J133
3
2
1
DUPLEX JAM SENSOR
PL5.4.1
PULL UP +3.3VDC
+3.3VDC
SG
DUP JAM SENSED(L)+3.3VDC
P/J13
10
11
12
P/J134
3
2
1
STACK FULL SENSOR
PL5.4.1
PULL UP +3.3VDC
SG
FULL STACK SENSED(L)+3.3VDC
+3.3VDC
P/J13
13
14
15
P/J135
3
2
1
TRAY 1 (MPT)
NO PAPER SENSOR
PL5.3.14
PULL UP +3.3VDC
SG
MSI NO PAPER SENSED(H)+3.3VDC
+3.3VDC
P/J13
16
17
P132
2
J132
1
1 2
TRAY 1 (MPT)
FEED SOLENOID
PL5.3.9
I/L +24VDC
MSI FEED SOL ON(L)+24VDC
Interlock
+24VDC
2
J191
1
1 2
TRAY 1 (MPT)
TURN ROLLER
CLUTCH
PL4.2.9
3
J192
1
2 2
REGISTRATION
CLUTCH
PL4.2.7
NC
P/J18
1
2
3
PULL UP +3.3VDC
+3.3VDC
SG
REGI PAPER SENSED(L)+3.3VDC
P/J181
3
2
1
REGISTRATION SENSOR
PL4.1.3
P/J19
3
4
I/L +24VDC
1 3
5
REGI CLUTCH ON(L)+24VDC
Interlock
+24VDC
P/J19
1
2
I/L +24VDC
MSI TURN CLUTCH ON(L)+24VDC
Interlock
+24VDC
P191
P192
s6300-329
