Wiring Diagrams 10-11
550-Sheet Feeder Plug/Jack Designators
550-Sheet Feeder Plug/Jack Designators
P/J Coordinates Remarks
80 I-205 Connects the OPTFDR Board and SIZE Harness.
81 J-204 Connects the OPTFDR Board and LOWP Harness.
82 J-205 Connects the OPTFDR Board and Drive Assembly.
83 I-205 Connects the OPTFDR Board and OPFREC Harness.
84 I-205 Connects the OPTFDR Board and OPFPLG2 Harness.
85 J-204 Connects the OPTFDR Board and OPFDR Harness.
86 I-205 Not Connected
171 G-208 Connects the Optional Feeder to the Print Engine.
172 G-210 Connects the Optional Feeders.
821 H-209 Connects the Paper Size Switch and SIZE2 Harness.
822 G-209 Connects the No Paper Sensor and OPFDR2 Harness.
823 F-209 Connects the Low Paper Sensor and LOWP Harness.
824 H-209 Connects the Feed Solenoid and OPFDR2 Harness.
825 G-209 Connects the Turn Clutch and OPFDR2 Harness.
To Next Page
