Xerox Phaser 6300 Service Manual

Error Messages and Codes 3-37
Replace Transfer Roller or
Transfer Roller Is at End of Life
The Toner Full Sensor indicates that the Transfer Roller requires replacement.
Applicable Status Code:
Code 206: Replace Transfer Roller
Warning: Transfer Roller is at End of Life
Initial Actions:
■ Print the Supplies Usage page to verify the remaining life and Transfer
Roller install date.
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Note
Look at the clear plastic window on the Transfer Roller. If toner is present in the
center of the window, the Transfer Roller is at end of life and needs to be
replaced. If no toner is visible, try cleaning the CTD (ADC) Sensor.
The Transfer Roller is at End of Life is a warning. Replace Transfer Roller is a
hard stop.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack References
■ Toner Full Sensor, PL5.2.20
■ Transfer Roller, PL5.1.4
■ TNRFULL/FSR Harness, PL5.2.30
■ Print Engine Map 2 - P/J Locator (page 10-6)
■ Print Engine Wiring Xerographics (1/2) (page 10-24)
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1
Check the following for evidence of fault or
damage:
■ Transfer Roller PL5.1.4
■ Toner Full Sensor PL5.2.20
Replace any
damaged parts.
Go to Step 2.
