Parts List 9-3
Using the Parts List
Only those parts listed with part numbers are available for order. Parts listed without
part numbers are only available as part of a parent assembly or Service Kit.
1. No.: The callout number from the exploded part diagram.
2. Part Number: The material part number used to order specific parts.
Note
An asterisk following the part number identifies parts common to the
Phaser 6250 and Phaser 6300/6350. All other parts are unique to the
Phaser 6300/6350 printers.
3. Name/Description: Name of the part and number supplied per order.
4. Parts throughout this manual are referenced PL#.#.#; For example, PL3.1.10
means the part is item 10 of Parts List 3.1.
5. A black triangle preceding a number followed by a parenthetical statement
indicates the item is a parent assembly, made up of the parts listed in parentheses
and enclosed by a dashed line.
6. The notation “(with X~Y)” following a part name indicates an assembly includes
components X through Y. For example, “1 (with 2~4)” means part 1 consists of
parts 2, 3, and 4.
7. The notation “J1<>J2 and P2” is attached to a wire harness. It indicates that
connector Jack 1 is attached to one end of the wire harness and connector J2 is
attached to the other end that is plugged into P2.
Legend:
Identifier Meaning
C C-ring
E E-ring
KL K-clip
S Screw
