Xerox Phaser 6300 Service Manual

Reference A-11
Service Diagnostics Tests
Service Diagnostics Tests and Utilities
Test Control Panel Display and Test Definition
Print Service Menu Map - Prints the Service Diagnostics menu then exits diagnostic mode.
General Status - Provides the following print engine status:
General Engine
Status
No Status To Report
-or one or more
Printer Status Messages (page A-4)
NOTE: This is current non-
sequential status since
entering diagnostics. If
Ready is reached, Status is
cleared.
No Status to Report = the printer
is online and ready to print.
Displays an engine status that will
prevent printing. Status is
displayed one line at a time.
Engine Board ROM
Version
Engine FW: #.#.# or Unknown
Engine NVRAM: #.#.# or Unknown
Option Feeder: #.#.# or Unknown
Displays the engine/feeder
firmware version installed, if
known.
Printer
Configuration
Memory: ###MB
Hard Drive: Not Installed or Installed
HCF/LTA: Installed or Not Installed
Displays current memory installed.
Detects presence of Hard Drive.
Detects presence of option feeder.
Reboot printer to update option
status. Do not lift engine from
optional tray to test.
Ambient
Temperature/
Humidity
Temperature: ##
o
C
Temperature: ##
o
F
Humidity: ## %
Displays the current Temperature
and Humidity for the printer.
Fuser Temperature
Temperature: ##
o
C
Temperature: ##
o
F
Displays the printer’s current Fuser
temperature.
Fault History Fault History Display
Fault History Master Clear
List Cleared
Displays Fault occurrence since
last power cycle. Cycle Power
displays following Master Clear.
Test Prints - Prints test prints stored in the Engine Control Board.
Blank Page Print Continuously prints blank pages until
Cancel is pressed.
See "Test Prints" on page 5-4,
"Adjustments" on page 6-3, and
"Resetting NVRAM" on page 6-4,
for specific test print information.
Standard Test Print Continuously prints the Step pattern
until Cancel is pressed.
Custom Test Print Prints the test pattern using the
custom print parameters until
Cancel is pressed.
Current Custom
Test Print Setup
Displays the print setup for the
Current Test Print.
Custom Test Print
Parameters
Set Custom Test Print parameters.
