General Information 1-7
Rear Panel
Image Processor Board
Transfer the following components, if installed, to the new board when replacing the
Image Processor Board.
1. Mode Select Port 4. USB Port
2. Serial Debug Port 5. Configuration Card Port
3. Ethernet Port 6. Test Print Button
s6300-3631234 5 6
RAM
NVRAM
Hard Drive
Configuration Card
s6300-380
