Parts List 9-61
Spring Kit
Spring Kit Contents - 116-2031-00
Part Reference Name/Description Quantity
PL3.3.10 Feed Spring H 2
PL4.1.2 Registration Roller Spring 1
PL5.1.6 Link Spring 1
PL5.2.3 Fuser Lock Lever Spring 1
PL5.2.7 Diode Spring F 1
PL5.2.12 Latch Spring 1
PL5.2.18 CTD (ADC) Sensor Spring 1
PL5.2.22 DTC Bias Spring 1
PL5.3.4 IDT1-1 Bias Spring 1
PL5.3.8 MPT Feed Spring 1
PL5.3.11 MPT N/F Spring 1
PL5.3.33 Earth Out2 Spring 1
PL5.3.34 MPT No Paper Sensor Actuator Spring 1
PL5.4.3 Exit Pinch Roller Springs 2
PL5.4.14 Duplex Jam Sensor Actuator Spring 1
PL6.1.4 Stopper Lever Release Spring 1
