1-14 Phaser 6300/6350 Color Laser Printer Service Manual
Functional Specifications
Functional Specifications
Characteristic Specification
Printing Process Imaging System: - 4-tandem drums, electro-photographic system using
intermediate drum transfer rolls (IDTs).
Exposure System: - Semiconductor laser, simultaneous scan by 4 beams.
Development System: - Dry type 2-component developer.
Fusing System: - Heat fusing, free nip-belt system.
Color Medium Yellow, Magenta, Cyan, and Black Toner Cartridges
Resolution /
Addressability
Standard
Enhanced
1200 x 600 dpi (default)
2400 x 600 dpi
1200 x 1200 dpi
Operating Modes Print Mode: Print Engine capable of making prints immediately.
Ready Mode: 20 seconds from completion of a print.
Sleep/ Low Power/ Power Saver Mode: Entered after a specified period of
Print Engine inactivity since completion of the last print.
Maximum Color
Coverage
6300N and DN configurations is 240% at 26 ppm
6350DP, DT, and DX configurations is 200% at 36 ppm
Print Speed Phaser 6350DP, 6350DT, and 6350DX Configurations
Resolution Letter/A4 Letter/A4 Duplex (ipm) Legal Legal Duplex (ipm)
Standard:
Enhanced:
Photo:
Transparencies
100-163 g/m
2
163-216 g/m
2
36/35
26/24
18/18
12
18/18
12
21/20
15/15
11/11
N/A
11/11
N/A
29
20
12
N/A
12
8
20
13
8
N/A
8
N/A
Print Speed Phaser 6300N and 6300DN Configurations
Resolution Letter/A4 Letter/A4 Duplex (ipm) Legal Legal Duplex (ipm)
Standard:
Enhanced:
Photo:
Transparencies
100-163 g/m
2
163-216 g/m
2
26/24
26/24
18/18
12
18/18
12
15/15
15/15
11/11
N/A
11/11
N/A
20
20
12
N/A
12
8
13
13
8
N/A
8
N/A
Warm-up Time 45 seconds from cold start (power off condition)
30 seconds from (standby)
