Xerox Phaser 6300 Service Manual

Wiring Diagrams 10-31
Upper Tray
P/J823
3
UPPER OPTFDR 2
BOARD
PL12.3.3
P/J80
1
2
4
3
PAPER SIZE
SWITCH
PL12.2.6
OPTION TRAY2 SIZE0 ON(L) +3.3VDC
OPTION TRAY2 SIZE1 ON(L) +3.3VDC
5
SG
NC
OPTION TRAY2 SIZE2 ON(L) +3.3VDC
P/J821
4
3
1
2
LOW PAPER
SENSOR
PL12.4.7
2
1
P/J81
1
2
3
PULL UP +3.3VDC
SG
OPTION TRAY2 LOW PAPER ON(H) +3.3VDC
P/J85
1
2
I/L +24VDC
OPTION TRAY2_TURN ON(L) +24VDC
P/J85
3
4
FEED SOLENOID
PL12.4.11
P824
2
J824
1
1 2
I/L +24VDC
OPTION TRAY2 FEED ON(L) +24VDC
P825
2
1
J825
1
2
TURN ROLLER
CLUTCH
PL12.4.4
P/J822
3
NO PAPER
SENSOR
PL12.4.7
2
1
P/J85
5
6
7
PULL UP +3.3VDC
SG
OPTION TRAY2 NO PAPER ON(H) +3.3VDC
P/J84
1
2
3
4
5
6
7
8
9
10
11
P/J83
10
9
8
7
6
5
4
3
2
1
NC
RXD
TXD
TRY_SNS_2
SG
+3.3VDC
SG
SG
I/L +24VDC
SG
I/L +24VDC
+3.3VDC
Interlock
+24VDC
+3.3VDC
Interlock
+24VDC
Interlock
+24VDC
+3.3VDC
s6300-338
