8-2 Phaser 6300/6350 Color Laser Printer Service Manual
Overview
This section contains the removal procedures for field-replaceable parts of the printer
listed in the Parts List. In most cases, the replacement procedure is simply the reverse
of the removal procedure. In some instances, additional steps are necessary and are
provided for replacement of the parts. For specific assemblies and parts, see the
"Parts
List" on page 9-1.
Standard Orientation of the Printer
When needed, the orientation of the printer is called out in the procedure as an aid to
locating printer parts. Refer to the following figure to identify the right, left, front, and
back sides of the printer.
s6300-124
Left
Rear
Right
Front
