10-24 Phaser 6300/6350 Color Laser Printer Service Manual
Xerographics (1/2)
ENGINE CONTROL
BOARD
PL9.1.16
P/J36
1
2
3
4
+5VDC
P/J52
13
12
11
P/J142
1
2
3
+5VDC
BTR_TONER_FULL(L)+3.3VDC
SG
TONER FULL SENSO
R
PL5.2.20
4
P/J191
3
2
1
1
P/J144
2
3
4
EEPROM BOARD
PL9.1.12
SG
+3.3VDC
CLOCK
DATA
5 1
2
3
4
P/J136
5
SG
ADC_VMON
GLED
ADC_VOUT
+5VDC
CTD(ADC) HOLDER
PL5.2.19
+5VDC
+3.3VDC
s6300-327
