9-60 Phaser 6300/6350 Color Laser Printer Service Manual
Note
Toner Cartridges installed at the time of manufacture contain sufficient additional
toner to prime the Auger Tubes without reducing the 4K life expectancy.
Service Kits
Service kits are developed to provide an easy means to obtain spare parts normally
associated with larger assemblies. A number of Service Kits have been developed for
the Phaser 6300/6350. The following tables list each kit’s contents.
Feed Roller Kit
The Feed Roller Kit provides replacement rollers for the Paper Pick Assemblies and a
universal Retard Roller Assembly.
Toner Cartridge Consumables
Description (capacity) Part Number
Yellow Toner Cartridge, Standard-Capacity 6300/6350 (4K)
Yellow Toner Cartridge, High-Capacity 6300 (7K)
Yellow Toner Cartridge, High-Capacity 6350 (10K)
Yellow Toner Cartridge, Metered 6300/6350 (10K)
106R01075
106R01084
106R01146
106R01088
Magenta Toner Cartridge, Standard Capacity 6300/6350 (4K)
Magenta Toner Cartridge, High-Capacity 6300 (7K)
Magenta Toner Cartridge, High-Capacity 6350 (10K)
Magenta Toner Cartridge, Metered 6300/6350 (10K)
106R01074
106R01083
106R01145
106R01087
Cyan Toner Cartridge, Standard-Capacity 6300/6350 (4K)
Cyan Toner Cartridge, High-Capacity 6300 (7K)
Cyan Toner Cartridge, High-Capacity 6350 (10K)
Cyan Toner Cartridge, Metered 6300/6350 (10K)
106R01073
106R01082
106R01144
106R01086
Black Toner Cartridge, Standard-Capacity 6300/6350 (4K)
Black Toner Cartridge, High-Capacity 6300 (7K)
Black Toner Cartridge, High-Capacity 6350 (10K)
Black Toner Cartridge, Metered 6300/6350 (10K)
106R01076*
106R01085
106R01147
106R01089
Feed Roller Kit Contents - 116-2035-00
Part Reference Name/Description Quantity
PL2.1.12 Universal Retard Roller Assembly 1
PL3.3.18 Feed Rollers 2
071-0942-00 Installation Instructions 1
