Xerox Phaser 6300 Service Manual

3-50 Phaser 6300/6350 Color Laser Printer Service Manual
Non-Phaser 6300/6350 Fuser
A CRUM-ID error indicates that a non-Phaser 6300 Fuser is installed.
Applicable Status Code:
Code 94: Fuser CRUM ID Error
Initial Actions:
■ Ensure that the Fuser latches are fully latched and cycle printer power.
■ If the problem persists, follow the procedure below
W
arn
i
ng
Avoid the potential of electric shock by removing the power cord from the
wall outlet prior to performing the following procedure.
Caution
Allow adequate time for the Fuser to cool before servicing the printer.
5
Check all pins on the RFID2 Harness
PL7.2.16 for continuity.
1. Disconnect P/J341 and P/J3411.
2. Check continuity between
J341<=>J3411.
Go to Step 6. Replace the
RFID2 Harness.
6
Check all pins on the RFID Harness
PL7.2.17 for continuity.
1. Disconnect P/J3411 and P/J34.
2. Check continuity between
P3411<=>J34.
Replace the Engine
Control Board
(
page 8-104).
Replace the RFID
Harness.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack References
■ Fuser, PL5.1.1
■ FSR/ADC Harness, PL5.2.28
■ Engine Control Board, PL9.1.16
■ Print Engine Map 2 - P/J Locator (page 10-6)
■ Print Engine Map 3- P/J Locator (page 10-7)
■ Print Engine Fuser Wiring (page 10-22)
Troubleshooting Procedure Table (Continued)
Step Actions and Questions Yes No
