Print-Quality Troubleshooting 5-21
5
CAUTION: Do not clean the Developer
Assembly rollers with a
cloth. Carefully remove
debris from the rollers using
tweezers or similar tool.
Remove the Developer Frame
Assembly (
page 8-78). Using a lint free
cloth, carefully clean the Laser window
and between each Developer
Assembly.
Does the image quality improve?
Complete Go to Step 6.
6
Replace the Developer Frame
Assembly (
page 8-78).
Does the image quality improve?
Complete Go to Step 7.
7
Replace the Laser Unit (page 8-76).
Does the image quality improve?
Complete Replace the Engine
Control Board
(page 8-104).
Troubleshooting Procedure Table (Continued)
Step Actions and Questions Yes No
