Service Parts Disassembly 8-51
8. Release the hook that holds the left side Roll Core on the Shaff, move the Roll
Core to the left.
9. Move the Feed Roller left until the pin on the shaft appears and remove the Feed
Roller.
Replacement Note
With the Solenoid engaged, the flat portion of the Feed roller should face the
Bottom Plate.
s6300-177
Bottom Plate
